Hand held rock drill Y19A
Application area
It is mainly used for rock development in small quarries, coal mine, lime water conservancy construction and national defense construction. Drilling and blasting, and construction of farmland and water conservancy.
Product characteristics
Small volume, light weight and less air consumption; It can also be matched with FT100 air leg and used as a small hand-held and air leg dual-use rock drill.
Application area
It is mainly used for drilling, drilling, blasting and secondary blasting in mines, railways, water conservancy and stonework projects.
Product characteristics
The operator can bear less vibration force of the machine, more powerful ballast return force, and the parts are firm and durable. Especially suitable for drilling vertical down blasting holes
|
Item No |
Weight Kg |
Length mm |
Drill tail specification mm |
Drill diameter mm |
|
Y26 |
26 |
650 |
H22x108+1 H25x108+1 |
34~42 |
|
Y19A |
19 |
600 |
H22x108+1 |
34~40 |
|
Piston diameter mm
|
Piston stroke mm
|
5bar working pressure |
|
|
Air consumption L/S |
Impact frequency Hz |
||
|
65 |
70 |
≤50 |
≥ 27 |
|
65 |
54 |
≤43 |
≥ 35 |
