Shen Feng Air Pick G10
Air pick
The tool is powered by compressed air. The compressed air is distributed to the two ends of the cylinder block by the tubular distribution valve in turn to make the hammer enter the complex impact movement, impact the tail of the pick and drill rod, and make the pick and drill rod drive into the rock or ore bed until it is split into pieces.
Purpose
Air pick is mainly used for crushing operations of reinforced concrete buildings, cement, permafrost, ice, soft ore, soft rock and road construction.
Scope of using
1. Mining soft rock
2. Coal mining in the coal mine, planing of column footpits, and opening of ditches
3. Broken concrete, frozen soil and ice breaking for construction and installation works
|
Item No |
G10 |
||
|
Weight (kg) |
10.6 |
||
|
Working pressure (bar) |
4 |
5 |
6.3 |
|
Impact frequency (Hz) |
≥ 15 |
≥ 16.5 |
≥ 16.5 |
|
Air consumption (L/S) |
≤16 |
≤20 |
≤26 |
|
Impact kinetic energy (J) |
≥ 32 |
≥ 39.3 |
≥ 43 |
|
Noise (dB) |
≥ 116 |
≥ 117 |
≥ 118 |
|
Piston diameter (mm) |
38 |
||
|
Piston stroke (mm) |
155 |
||
|
Air hose inner diameter (mm) |
16 |
||
|
Drill tail specification (mm) |
Φ25x75 |
||
|
Size (mm) |
575x170x90 (+20) |
||
|
Item No |
G10L |
||
|
Weight (kg) |
10.6 |
||
|
Working pressure (bar) |
4 |
5 |
6.3 |
|
Impact frequency (Hz) |
≥ 15 |
≥ 16.5 |
≥ 16.5 |
|
Air consumption (L/S) |
≤16 |
≤20 |
≤26 |
|
Impact kinetic energy (J) |
≥ 32 |
≥ 39.3 |
≥ 43 |
|
Noise (dB) |
≥ 116 |
≥ 117 |
≥ 118 |
|
Piston diameter (mm) |
38 |
||
|
Piston stroke (mm) |
155 |
||
|
Air hose inner diameter (mm) |
16 |
||
|
Drill tail specification (mm) |
Φ24x70 |
||
|
Size (mm) |
575x170x90 (+20) |
||
